Synchronous motors (electric spindles) use permanent magnet rotors. The permanent magnet rotor generates a voltage as it rotates, called back EMF. The magnitude of back EMF increases with speed. The spindle drive has a fixed rated output voltage. When the motor's back EMF exceeds the drive's rated voltage, the drive must apply field weakening to increase speed further—it generates an additional current to counteract the motor's back EMF. The higher the speed, the larger the field weakening current, which increases coil temperature. This is a normal physical phenomenon for high-power, high-speed motors.
For high-precision spindles, slightly higher coil current and temperature are acceptable, as long as they stay within the coil's tolerance. Our design focuses on increasing cooling flow and heat dissipation to remove heat from the coil before it transfers to bearings and other components.
What are the advantages of TDM hydrostatic spindle bearings?
Compared to traditional rolling bearing spindles, hydrostatic bearing spindles can deliver higher power at the same speed. For example, at 120,000 rpm, rolling bearing spindles typically produce around 2kW, while our hydrostatic spindles can reach 6kW. Hydrostatic spindles also offer two orders of magnitude higher rotational accuracy than rolling bearing spindles: typical rolling bearing spindles have ~1μm runout, while our hydrostatic spindles are below 0.05μm.
Compared to air bearing spindles, while maintaining similar rotational accuracy, our spindles have 5-8 times higher rigidity than same-size air bearing spindles, making them ideal for ultra-precision machining.
Compared to other hydrostatic spindles: domestic hydrostatic spindles typically have 0.2-0.3μm accuracy, while our imported ones are below 0.05μm, typically 0.02-0.03μm. Also, currently no other hydrostatic spindle in the world exceeds 100,000 rpm, except TDM. Our hydrostatic spindles can reach up to 250,000 rpm while maintaining accuracy, power, and rigidity.
For ultra-precision machining, TDM hydrostatic spindles are unquestionably the best choice.
(1) TDM SA specializes in high-rigidity, high-precision spindles for hard metal machining. This is completely different from spindles used for processing soft materials like wood, stone, or rubber (which are more common in Italy). Soft material spindles have much lower requirements for rigidity, accuracy, and even reliability, and are correspondingly cheaper.
(2) Compared to other German and Swiss spindles also used for hard metal machining, our biggest advantage is full customization. Even if a customer only needs 1 unit, we can customize it, without significant increase in cost or lead time.
(3) TDM spindles are designed, manufactured, assembled, and tested entirely at our Swiss factory. We use only top-tier global brand components, which ensures the highest quality standards for our spindles and motors.
(4) As a Swiss specialist in high-quality spindles, like Swiss knives and watches, we focus on small-to-medium size (spindle body diameter below 280mm), high-precision, high-reliability products. Very large, heavy-duty spindles are not our strength.
All our spindles have taper bore and end face runout below 1.5μm (European industry standard is 2μm). The combined surface vibration at front and rear bearings does not exceed 1mm/s (industry standard is 1mm/s at each bearing location).
(1) Drain the cooling fluid from the spindle cooling system.
(2) Disconnect the spindle power cable from the machine tool.
(3) Cover the spindle taper with a plastic cap, and plug all other air/fluid fittings.
(4) Coat the surface with grease or anti-rust oil, then wrap with waterproof paper.
(5) Store in a dry, well-ventilated environment.
(6) Check and re-grease regularly.
(7) Before reusing, run a break-in period as required.
